Mill Resharpener - M312
End Mill Sharpener for 3mm to 12mm tool diameter.
End Mill Tip Angle Setting from 0 deg. to about12+ deg, Industrial Grade Sharpener in solid, rigid all metal construction.
End mill Sharpener Series to sharpen two-flute end mills, three-flute end mills, and four-flute end mills, as well as flat bottom drills.
End Mill Tip Angle Setting from 0 deg. to about12+ deg, Industrial Grade Sharpener in solid, rigid all metal construction.
End mill Sharpener Series to sharpen two-flute end mills, three-flute end mills, and four-flute end mills, as well as flat bottom drills.
Model :
M-312
Portable Mill Resharpening Machines
MODEL: M-312
FLUTES MILL DIAMETER : Ø 3 ~ 12mm
SHARPEN ANGLE: 0° ~ 3°
POWER SUPPLY: AC 110V 60Hz / 50Hz ; AC220V (Opt.)
R.P.M. OF MOTOR:5000 ± 300 R.P.M.
MACHINE SIZE L:3000mm x W:160mm x H:210mm
STANDARD ACCESSORIES :
CHUCK SETS FOR 2 / 4 Flutes Mill
CHUCK SETS FOR 3 / 6 Flutes Mill
ER20 COLLET x 5 PCE
EXTENSION ROD x 2 PCE for Drill 2 / 2.5 / 3/ 3.5mm
HEXAGON WRENCH x 3 PCE
POWER CORD x 1 PCE
FUSE x 1 PCE
OPT.
Diamond Dust Grinding Wheel x 1 PCE
